מפרט טכני
Input
- USB
- 2.0
Outputs
- Analogue
- 2 x RCA Jacks
- Digital
- 1 x Coaxial RC Jack
General Specifications
- Sample Rate
- 96kHz/24 bit
- THD+N
- 0.05% (ref. 0dBFS)
- Signal to Noise
- >-80dB
- Analogue Output Level
- 2V
- Coax SPDIF
- 500mV ±50mV
- Frequency Response
- 20Hz to 48kHz ±0.5dB
- Digital to Analogue Converter
- Delta Sigma DAC
- Time Delay
- <18rms
- RF Band
- >2.4GHz
- Transmission Range
- 40m (line of sight)
Weight & Dimensions
- Gross Unit Dimensions*
- 135 x 35 x 70mm
5 3/8 x 1 3/8 x 2 3/4″** - Transmitter
- 73 x 35 x 15mm
2 7/8 x 5/8 x 1 7/16 - Net Weight
- 0.38kg (0.80lb)
- Shipping Weight
- 0.62kg (1.35lb)
*Gross dimensions include feet, extended buttons and rear panel terminals.
**Non-metric measurements are approximate.
