מפרט טכני
Weight
20.6kg (45.4 lbs)
Dimension (H x W x D)
1062 x 244 x 328 mm
1116 x 357 x 328 mm (with Plinth)
1116 x 357 x 328 mm (with Plinth)
Design
2.5-way bass reflex
Unit Measurement
Pair
Sensitivity
91dB (2.83V/1m)
Frequency Range
38Hz (-6dB)
Frequency Response
44Hz-28kHz (±3dB)
Maximum Output
113dB
Amplifier Requirements
15-200W
Nominal Impedance
8 Ohms (min.3.2 Ohms)
Drive Units
200mm (8in.) aluminium Uni-Q
38mm (1.5in.)vented aluminium dome HF
200mm (8in.) aluminium LF
2 x 200mm (8in.)aluminium ABR
38mm (1.5in.)vented aluminium dome HF
200mm (8in.) aluminium LF
2 x 200mm (8in.)aluminium ABR
Crossover Frequencies
2.2kHz
Finishes
Satin Black / Satin White
