מפרט טכני
MC
- Input Impedance (R and C)
- 100 Ohm + 180pF
- Gain at 1kHz
- 60dB
- Input Sensitivity (ref. 200mV output)
- 0.3mV
- Signal to Noise Ratio
- 78dB (A weighted, with cartridge connected)
- Input Overload (20Hz/1kHz/20kHz)
- 0.8/9/84mV
- Rated Distortion (THD 20Hz – 20kHz)
- <0.03%
- RIAA Response Accuracy
- ±0.3dB
MM
- Input Impedance (R and C)
- 47 kilohm + 200pF
- Gain at 1kHz
- 35dB
- Input sensitivity (ref. 200mV output)
- 2.5mV
- Signal to Noise Ratio
- 80dB (A weighted, with cartridge connected)
- Input overload (20Hz/1kHz/20kHz)
- 10/102/950mV
- Rated Distortion (THD 20Hz – 20kHz)
- <0.03%
- RIAA response accuracy
- ±0.3dB
Line Out
- Output Impedance
- 100 Ohm
- Maximum Output Level
- 5.3V
General Specifications
- AC Supply
- External 23.5V DC
- Dimensions excl. Power supply (W x H x D)
- 135 x 49 x 72mm
5 5/16 x 1 15/16 x 2 7/8″
C298
