מפרט טכני
Model
LS50 Meta
Design
Two-way bass reflex
Drive Units
Uni-Q Driver Array:
HF: 25 mm (1 in.) vented aluminium dome with Metamaterial Absorption Technology
MF/LF: 130 mm (5.25 in.) aluminium cone
HF: 25 mm (1 in.) vented aluminium dome with Metamaterial Absorption Technology
MF/LF: 130 mm (5.25 in.) aluminium cone
Crossover Frequency
2,1 kHz
Frequency Range (-6db)
47 Hz – 45 kHz
Typical In-room Bass Response (-6db)
26 Hz
Frequency Response (±3db)
79 Hz – 28 kHz
Harmonic Distortion (90db, 1m)
<0,4% 175 Hz – 20 kHz
<0,1% 300 Hz – 10 kHz
<0,1% 300 Hz – 10 kHz
Maximum Output
106 dB
Amplifier Power (Recommended)
40-100 W
Nominal Impedance
8 Ω (min. 3,5 Ω)
Sensitivity (2.83V/1m)
85dB
Weight*
7.8 kg (17.2 lbs.)
Dimension (H X W X D) With Terminal*
302 x 200 x 280.5 mm (11.9 x 7.9 x 11.0 in.)
* Measurement per unit
