מפרט טכני
Nominal Impedance
4 Ohm
Sensitivity
89dB (2.83V/ 1m)
Crossover Response
2.2kHz
Frequency Response
55Hz – 28kHz (±6dB) open backed
Drive Units
LF: 3 x 100mm (4 in.)
MF: 100mm (4 in.)
HF: 19mm (0.75 in.) Uni-Q
MF: 100mm (4 in.)
HF: 19mm (0.75 in.) Uni-Q
Recommended Amplifier Power
10 – 150W
Product External Dimension (H X W X D)
490 x 128 x 81 mm (19.29 x 5.04 x 3.19 in.)
Cut-Out Dimensions (H X W)
476 x 114mm (18.74 x 4.49 in.)
Mounting Thickness
Ceiling Thickness (Maximum): 24mm (0.95 in.)
Ceiling Thickness (Minimum): 6mm (0.24 in.)
Ceiling Thickness (Minimum): 6mm (0.24 in.)
Mounting Depth From Surface
76mm (3.0 in.)
Optional Rough In Frame
RIF4100L
Net Weight
3 kg (6.61 lbs)
Unit Measurement
Piece
Downloads
Remarks
KEF reserves the right, in line with continuing research and development, to amend or change specifications. E&OE. THX, the THX logo, and SELECT2 are trademarks of THX Ltd. THX and the THX logo are registered in the U.S. and other jurisdictions. All rights reserved.
