מפרט טכני
Nomimal Impedance
8 Ohm
Sensitivity
89dB (2.83V/ 1m)
Crossover Frequencies
3.0kHz
Frequency Response
38Hz – 34kHz (±6dB) open backed
Drive Units
LF: 160mm (6.5in.)
HF: 19mm (0.75in.) Uni-Q
HF: 19mm (0.75in.) Uni-Q
Recommended Amplifier Power
10 – 125W
Product External Dimension (H X W X D)
303 x 223 x 97.5 mm (11.93 x 8.78 x 3.84 in.)
Cut-Out Dimensions (H X W)
274 x 194 mm (10.79 x 7.64 in.)
Mounting Thickness
Ceiling Thickness (Maximum): 30mm (1.19 in.)
Ceiling Thickness (Minimum): 3mm (0.12 in.)
Ceiling Thickness (Minimum): 3mm (0.12 in.)
Mounting Depth From Surface
91mm (3.58in.)
Optional Rough In Frame
RIF160L
Optional Rear Enclosure
RNC160L
Net Weight
2.05kg (4.51lbs.)
Unit Measurement
Piece
