מפרט טכני
Colour
White
Nominal Impedance
8 Ohms
Sensitivity
91dB (2.83V/ 1m)
Frequency Response
50Hz – 20kHz (±6dB) open backed
Crossover Response
3.2kHz
Drive Units
LF: 160mm (6.5in.)
HF: 19mm (0.75in.)
HF: 19mm (0.75in.)
Product External Dimensions (H X W X D)
223 x 223 x 90.5 mm (8.78 x 8.78 x 3.56 in.)
Cut-out Dimensions (H X W)
194 x 194 mm (7.64 x 7.64 in.) Without back can
Mounting Thickness
Ceiling Thickness (Maximum): 30mm (1.19 in.)
Ceiling Thickness (Minimum): 3mm (0.12 in.)
Ceiling Thickness (Minimum): 3mm (0.12 in.)
Mounting Depth From Surface
84.5mm (3.33in.) Without back can
Optional Rough In Frame
RIF160S
Optional Rear Enclosure
RNC160S
Net Weight
1.80kg (4.0lbs.)
Unit Measurement
Piece
