מפרט טכני
Nomimal Impedance
8 Ohms
Sensitivity
90dB (2.83V/ 1m)
Frequency Response
52Hz – 20kHz (+/-6dB) open-backed
Crossover Frequencies
2.5kHz
Drive Units
LF: 130mm (5.25in.)
HF: 16mm (0.6in.)
HF: 16mm (0.6in.)
Recommended Amplifier Power
10-80W
Product External Dimensions
Diameter : 193.4mm (7.61in.)
Depth : 81mm (3.19n.)
Depth : 81mm (3.19n.)
Cut-Out Dimensions
Diameter : 158mm (6.22in.)
Mounting Thickness
Ceiling Thickness (Maximum): 33mm (1.3 in.)
Ceiling Thickness (Minimum): 6mm (0.24 in.)
Ceiling Thickness (Minimum): 6mm (0.24 in.)
Mounting Depth From Surface
77.5mm (3.05in.)
Optional Rough In Frame
RIF130R
Optional Rear Enclosure
RNC130R
Net Weight
1.2kg (2.7lbs)
Unit Measurement
Piece
