מפרט טכני
Nominal Impedance
4 Ohms
Sensitivity
83dB (2.83V/lm)
Frequency Response
90Hz-27kHz (+/-6dB)
130Hz-27kHz (+/-6dB) with back can
130Hz-27kHz (+/-6dB) with back can
Crossover Response
3.5kHz
Drive Units
LH: 75mm (3in.) Uni-Q
HF: 16mm (0.6in.)
HF: 16mm (0.6in.)
Recommended Amplifier Power
10 – 50W
Product External Dimensions
Diameter: 136mm (5.4in.)
Depth: 57mm (2.2in.)
Depth: 110mm (4.3in.) with back can
Depth: 57mm (2.2in.)
Depth: 110mm (4.3in.) with back can
Cut-Out Dimensions
Diameter: 118mm (4.6in.)
Mounting Thickness
Ceiling Thickness (Maximum): 22mm (0.87 in.)
Ceiling Thickness (Minimum): 6mm (0.24 in.)
Ceiling Thickness (Minimum): 6mm (0.24 in.)
Mounting Depth From Surface
52mm (2in.)
103mm (4.1in.) with back can
103mm (4.1in.) with back can
Net Weight
0.50kg (1.10lbs)
0.65kg (1.44lbs) with back can
0.65kg (1.44lbs) with back can
Unit Measurement
Piece
