Line In / Headphone Out
THD (20 Hz – 20 kHz)
<0.03 % in 300 ohms at 2 V out
Signal-to-Noise Ratio
>100 dB (A-weighted, 32 ohms, ref. 2V out, unity gain)
Frequency response
±0.3 dB (20 Hz – 20 kHz)
Line In / Speaker Out
Continuous output power into 8 ohms and 4 ohms
THD (20 Hz – 20 kHz)
Signal-to-Noise Ratio
>95 dB (A-weighted, 500 mV input, ref. 1 W out in 8 ohms) >97 dB (A-weighted, 500 mV input, unity gain in 32 ohms)
Clipping power (at 1 kHz 0.1 % THD)
>45 W in 8 ohms >60 W in 4 ohms
IHF dynamic power
8 ohms: 90 W 4 ohms: 120 W 2 ohms: 170 W
Damping factor
>200 (ref. 8 ohms, 1 kHz)
Frequency response
±0.3 dB (20 Hz – 20 kHz, Tone Defeat ON) Treble: ± 5dB at 10 kHz Bass: ± 8 dB at 100 Hz
Channel separation
>70 dB (1 kHz)
Maximum input level
4.3V (1 kHz THD 0.1%)
Input sensitivity (for 40 W in 8 ohms)
200 mV
Phono In / Speaker Out
THD (20 Hz – 20 kHz)
<0.03 % (1 W to 40 W, 8 ohms and 4 ohms)
Signal-to-Noise Ratio
>75 dB with IHF MM cartridge (A-weighted, ref. 5mV input 1 kHz and 1W output in 8 ohms)
Frequency response (RIAA deviation)
+0.3 dB (20 Hz – 20 kHz, Tone Defeat ON)
